COMBISART 3-BRANCH MANIFOLD FILTER
Combisart® system for microbiological analysis or particle count in quality assurance. The system features a modular design and field-proven standard accessories to make your choice easier. At the heart of the Combisart® system is a stainless steel manifold, designed to accommodate all types of filter holders and funnels, such as ready-to-use funnels, flammable units, like stainless steel funnels for colony counting and autoclavable glass and polycarbonate filter holders.
3-branch Manifold
The Sartorius Combisart® system enables you to select the optimal hardware and consumables for your needs in microbiological analysis or particle count in quality assurance. Combisart® features a modular design and field-proven standard accessories to make your choice easier. The heart of the Combisart® system is a stainless steel manifold designed to accommodate all types of filter holders and funnels such as:- Ready-to-use units Biosart® 100 Monitors- Ready-to-use units Biosart® 250 Funnels- Flammable units such as stainless steel funnels for colony counting- Autoclavable glass filter holders- Autoclavable polycarbonate filter holders.
- Sterile venting of each membrane after filtration
- Sterilisation acc. to ISO 8199
- Special polished stainless steel surfaces allow easy cleaning & rinsing
- Filtration of three or six samples in parallel
- Easy pouring out of non-filterable samples
- Equally easy for right- and left-handed users
- Maximum flexibility due to different set-ups
- Space-saving in the autoclave
- Stainless steel 304 - long lifecycle
| Product properties | |
| Material | Silicone flat gasket, silicone seal |
| Primary Product Type | Manifolds |
| Filtration area | 12.5 cm² |
| Number of Filter Holders | 3 |
| Filter Holder | Removable |
| Technical attributes | |
| Stainless steel quality | High-grade stainless steel=== B.S. 304S31|AISI 304 |
| Funnel capacity | Without funnel |
| Suitable membrane filter diameter | 47 / 50 mm |
| Number of frits included | 0 |
| Application | Microbial Enumeration |
| Market | Food & Beverage` Environmental/Water Testing |
| Inlet | (for branches only) Female threads, TR 20 x 2 |
| Outlet | (for branches only) Hose nipple, DN 10 |
| Outlet spouts (individual system) | 10 mm outside diameter |
| Sterilization Procedures | By autoclaving (max. 134 °C)` By dry heat (max. 180 °C)` By flaming` By other methods acc. to ISO 8199 |
Combisart® — The Economic Way for Fast and Reliable Colony Counting Click Here
Microbiological Testing of Foods, Beverages, Drinking Water and Pharmaceuticals Click Here
Monitoring the quality of beverages, water and foods…Click Here
Combisart® — Vacuum Filtration Systems for Colony Count and Particle Counting Click Here
Combisart® manifold with sterile vented filter station(s) Click Here
