CORIO CD-200F REFRIGERATED/HEATING CIRCULATOR
CORIO CD-200F Refrigerated/Heating Circulator
The new generation of laboratory circulators for routine work and standard tasks
Refrigerated / Heating Circulators of the new CORIO™ series distinguish themselves with a great price-to-performance ratio. They are ideal for all standard tasks and routine work in laboratories and industry.
Your advantages
- Models for internal and external applications
- Bright, white, easy to read display
- Very quiet
- Easy pump change-over (internal and external circulation)
- External pump connections (M16x1)
- USB connection
- Space-saving cooling coil design yields more usable space in the bath tank
- Bath lid and drain tap included
- Removable ventilation grid
- Refrigeration unit without side vents
- Class III (FL) according to DIN 12876-1
| Technical Data | ||||
| Order No. | 9012701 | |||
| Model series | CORIO | |||
| Category | Refrigerated - Heating Circulators | |||
| Working temperature range (°C) | -20 ... +150 | |||
| Temperature control | PID | |||
| Temperature stability (°C) | ±0.03 | |||
| Setting / display resolution | 0.01 – 0.1 °C | |||
| Temperature Display | LED | |||
| Heating capacity (kW) | 1 | |||
| Cooling capacity (Medium Ethanol) | °C | 20 | 0 | -20 |
| kW | 0.22 | 0.17 | 0.06 | |
| Pump capacity flow rate (l/min) | 15 | |||
| Pump capacity flow pressure (psi) | 5.08 | |||
| Bath opening / bath depth (W x L / D inch) | 5.1 x 5.9 / 5.9 | |||
| Pump connections | M16x1 | |||
| Barbed fittings diameter (inner dia. / mm) | 8 / 12 | |||
| Filling volume (liters) | 3 ... 4 | |||
| Refrigerant stage 1 | R134a | |||
| Filling volume refrigerant stage 1 (g) | 70 | |||
| Global Warming Potential for | 1430 | |||
| Carbon dioxide equivalent stage 1 (t) | 0.1 | |||
| Ambient temperature | 5...40 °C | |||
| Dimensions W x L x H (inch) | 9.1 x 15.4 x 25,6 | |||
| Weight (LBS) | 57.4 | |||
| Included with each unit | 2 each barbed fitting for tubing 8 and 12 mm inner dia. (pump connections M16x1 male) | |||
| Bath tank | Stainless steel | |||
| Bath cover | integrated | |||
| Cooling of compressor | Air |
CORIO CD-200F Product data sheet Click Here
CORIO CD-200F Operating Manual Click Here
CORIO Brochure Click Here
