Stirring Water Bath 20L., 1 stirring

Category

Close
    1. Heating Circulator
    2. Highly Dynamic Control System
    3. Recirculating Cooler
    4. Refrigerated Circulator
    5. Shaking Water Bath
    6. Water Bath
    7. Accessories (Water Bath)
    8. Bead Bath


2MJC-SWB-20L-1

Stirring Water Bath 20L., 1 stirring


Cat. No. : 2MJC-SWB-20L-1
Brand : : Major Science




The MS Stirring Water Bath series packed with built-in thermostatic baths are innovative product line to provide precise temperature control and excellent mixing performance for a wide range of laboratory applications. The built-in stirring mechanism not only provides outstanding temperature uniformity, but also applies a stirring mixture function. The 10L or 20L stainless steel tank can operate flask(s) containing a moderate amount of solution simultaneously. Single stirring mechanism model and multi-stirring models are available for your preference.

Compatible Bottle of SWB -20L -3

The size of different brand bottle may vary slightly. Please refer the following table as reference only.



≤500ml

1L

2L

 proimages/5-Stirring_Water_Bath/Bottle-01.png

3

3

2

(position 1 & position 3)

proimages/5-Stirring_Water_Bath/Bottle-02.png

3

2

(position 1 & position 3)

2

(position 1 & position 3)*

 proimages/5-Stirring_Water_Bath/Bottle-03.png

3

3

2

(position 1 & position 3)

**Teflon Stir Bar, Cylindrical, L≤60 mm.
*When 2L Erlenmeyerflask is applied, it may be too high for thelid of water bath to put on.

 • Microprocessor control with digital performance for precise, accurate control

• Built-in magnetic stirring mechanism for water agitation, water temperature uniformity and medium solution mixing

• Stirring speed control

• LCD screen shows temperature and timer simultaneously

• User temperature calibration

• Safety device: warning indication on screen to avoid overheating and automatic shut down

• Multiple stirring mechanism capability

• Data Logging software available

proimages/5-Stirring_Water_Bath/SWB-B002.png
Max. Capability: 15 sets of 250ml flasks
                           8 sets of 500ml flasks

 proimages/5-Stirring_Water_Bath/SWB-B001.png

proimages/5-Stirring_Water_Bath/SWB-A002.png Temp. Set Value : 65 oC

proimages/5-Stirring_Water_Bath/SWB-A003.png Initial Temp. Value : 17 oC

 Water Volume : 12 liters

Process Time : approx. 60mins

 proimages/5-Stirring_Water_Bath/SWB-A005.png

 proimages/5-Stirring_Water_Bath/SWB-A006.png

 proimages/5-Stirring_Water_Bath/SWB-A007.png

Concave lid design allows condensation flow back to the tank.



Side opening of the lid to allow minimum evaporation while maintaining water bath temperature.

Water Circulation Function

proimages/5-Stirring_Water_Bath/SWB-A008.png Magnetic Agitator

proimages/5-Stirring_Water_Bath/SWB-A009.png Stir bar



Cat. No.

SWB-20L-1

SWB-20L-3

Number Of Stirring Mechanisms

1

3

Stirring Speed

400-1500rpm (measured by percentage)

Bath Capacity

Approx. 5.28gal (20L)

Water Circulation Function

Yes

Display

LCD

Heating Power

800W

Controller

Digital microprocessor controller

Bath Temperature

5 oC above ambient to 99 oC

Temperature Increment

0.1oC

Temperature Accuracy

±0.2 oC at 37 oC

Temperature Calibration

Yes

Timer

99 (hr): 59 (min) / Continuous

Safety Device

Warning indication on screen with alarm and automatic shut down

Operating Temperature

Ambient to 40 oC

Bath Tank Material

304 stainless steel

Bath Inner Dimension (WxLxH)

Approx. 11.8"x19.7"x5.9" (300x500x150mm)

Dimension (WxLxH) (without lid)

Approx. 13"x21.3"x9.5" (330x540x240mm)

Rear Drainage Port

Yes

Material

Painted iron metal

Lid Material

Polycarbonate with stainless steel handle

Communication Port

RS232

Weight

Approx. 30.9lb (14kg)

Rated Voltage

110V / 220V~








Cat. No.

Product Description

SWB-LID20

Transparent lid for 20L Stirring Water Bath

SWB-RS232

RS 232 cable for data logging

SWB-DLSW

Data Logging software package

SWB-DLSW-R

Data Logging software package, include a RS 232 cable



 Catalogue_W14-StirringBath Click Here
Brochure-017-StirringWaterBath  Click Here
